Vuzix Blade 2

Vuzix Blade 2 Specifications

Optics

• Display resolution: 480x480 colour display
• Display type: Wave Guide Projection Technology
• Aspect: 1:1 ratio
• Field of View (diagonal): 20 degrees, equivalent to a 6 in. mobile device held at arm's length (17 inches)
• Brightness: > 2000 nits
• 24-bit color
• Right eye display
• Prescription inserts available
• All lenses UV protected

Certifications

• ANSI Z87.1 safety certification
• Full UV protection lenses

Controls

• Multilingual voice control capabilities
• 2-axis touchpad with multi-finger support
• Companion app for Android & iOS devices

System

• Andriod 11 OS
• 40GB built-in memory
• Quad Core ARM CPU
• Internal LiPo rechargeable batteries

Audio

• Integrated stereo in-temple speakers
• Dual noise-cancelling microphones

Connectivity

• 5.0 and 2.4GHz WiFi and Bluetooth wireless
• USB 2.0 Micro-B

Camera

• 8-megapixel camera
• Auto-focus
• Streaming video
• Integrated barcode scanner

Integrated Head Tracker

• 3-degree of freedom head tracking
• 3 axis gyro
• 3 axis accelerometer
• 3 axis mag/integrated compass

Environment

• Operating temperature 0ºC to 35ºC
• Operating humidity 0% to 95% RH
• Storage temperature -30ºC to 70ºC
• Storage humidity 0% to 95% RH
